Natural gas reciprocating type gas compressor station
[ Edit: admin     Created Date: 2013-05-05   Readed Times:      Font:big middle small]


Natural gas reciprocating type gas compressor station

Natural gas compressor station

"D" type air cooled CNG Compressor

"D" type Air cooled CNG standard compressor station

SN

Model

Capacity
Nm3/h

Inlet pressure
MPa

Outlet pressure
MPa

Type/Stage

Lubricating

Cooling

Motor power
KW

Dimension
L*M*H  mm

Weight
Kg

Note

1

DF-0.4/(48-75)-250
CNG Compressor

1100~1800

4.8~7.5

25

D/2

Oil inject

Air Cooled

110

4000*2250*2400

5500



2

DF-0.5/(22-48)-250
CNG Compressor

650~1400

2.2~4.8

25

D/2

110

4000*2250*2400

5500



3

DF-0.8/(14-22)-250
CNG Compressor

700~1100

1.4~2.2

25

D/3

110

4000*2250*2400

5500



4

DF-1.2/(6-14)-250
CNG Compressor

500~1000

0.6~1.4

25

D/3

110

4000*2250*2400

5500



5

DF-1.6/(3.5-6)-250
CNG Compressor

430~670

0.35~0.6

25

D/4

110

4000*2250*2400

5500



6

DF-2.1/(1-3.5)-250
CNG Compressor

250~550

0.1~0.35

25

D/4

110

4000*2250*2400

5500

"M" type water cooled CNG Compressor

"M "type water cooled CNG Compressor station

SN

Model

capacity
Nm3/h

Inlet Pressue
MPa

Outlet pressure
MPa

Structure/stage

Lubricating

Cooling

Motor power
KW

Dimension
L*M*H mm

Weight
Kg

Note

1

D-0.8/(48-75)-250
CNG Compressor

2200~3600

4.8~7.5

25

D/2

Oil inject

Water cooled

220

4500*2600*1500

6500



2

D-1/(22-48)-250
CNG Compressor

1300~2800

2.2~4.8

25

D/2

220

4500*2600*1500

6500



3

D-1.6/(14-22)-250
CNG Compressor

1400~2200

1.4~2.2

25

D/3

220

4500*2600*1500

6500



4

D-2.4/(6-14)-250
CNG Compressor

1000~2000

0.6~1.4

25

D/3

220

4500*2600*1500

6500
